Chapter 3: EIU datafill 71
DMS-100 Family EIU User Guide TELECOM12
LIUSLOT 8 to 31 Link interface slot
Enter the slot number, at the host LIM,
on which the EIU resides.
The EIU occupies two card slots.
The left-most card represents the
logical location of the card.
All the shelves that are datafilled on a
particular controller must be of the
same type (two-slot shelves).
LOAD alphanumeric
(vector of up to 8
characters) Software load name
Enter the table software load name
applicable to the EIU.
This load is found in table PMLOADS.
PROCINFO see subfield Processor information
This field specifies the product
engineering code (PEC) of the
processors used in the LIU.
This field consists of subfield
PROCPEC.
PROCPEC NTEX22BA or
NTEX22BB
NTEX22CA Processor product engineering code
Enter the PEC of the processor card
used in the EIU as follows:
• NTEX22BA and NTEX22BB are the
PECs for the 8-Mbyte integrated
processor and F-bus interface
cards. The difference between the
NTEX22BA and NTEX22BB cards
is in firmware only, the hardware is
identical.
• NTEX22CA has a 32-Mbyte
integrated processor and F-bus
interface card.
CARDINFO This field identifies the PEC of EIU
circuit packs. The EIC PEC code is
NT9X84AA and the Ethernet interface
paddle board (EIP) PEC code is
NT9X85AA.
Table 11 Field descriptions for table LIUINV for EIU datafill (continued)
Field Subfield or
refinement Entry Explanation and action
(Sheet 3 of 4)
