Appendix F: EIU supported configurations 169
DMS-100 Family EIU User Guide TELECOM12
Figure 42 Interface configuration part 1
TABLE LIUINV
EIU 1 LIM 0 1 26 ERS09BB NTEX22BB NT9X84AA NT9X85AA YES 000075F17009
EIU 2 LIM 0 2 14 ERS09BB NTEX22BB NT9X84AA NT9X85AA YES 000075F17015
TABLE IPNETWRK
1 47 105 150 1 12 $ (EIU_INTERFACE EIU 1) (DFLT_INTERFACE Y) (DFLT_GTWY_IPADDR 47 105 150 4)
2 47 105 150 2 12 $ (EIU_INTERFACE EIU 2) (DFLT_GTWY_IPADDR 47 105 150 4)
TABLE IPHOST
0 CM 0 64 32 32
Can be another
subnet or new
network on this
side of external
router
classA . networkidB . subnetX . hostZ classA . networkidB . subnetX . hostZ
47.105.150.2 47.105.150.3 47.105.150.1
External
router
Subnet 1 Subnet 1 Base_Tel-3
Host
EIU 1
EIU 2
CM
255.255.240.0 router mask Default EIU SubnetX size
47.105.150.1
MAC address
Note: The CM node can support up to 16 different IP addresses.
