102 Chapter 3: EIU datafill
297-8991-910 Standard 03.01 August 1999
Sample datafill for table EXNDINV
Figure 24 shows sample datafill for table EXNDINV for an EIU.
Figure 24 Datafill example for table EXNDINV
MAJSCPT 0 to 6 Major alarm scan point
Enter the scan point associated with the
major alarm for the node.
MINSCPT 0 to 6 Minor alarm scan point
Enter the scan point associated with the
minor alarm for the node.
Table 26 Field descriptions for table EXNDINV for EIU datafill (continued)
Field Subfield or
refinement Entry Explanation and action
(Sheet 5 of 5)
EXNDKEY ENNAME ENADDR ENFNAME ENSITE ENLOCN ENTYPE ENINFO ENPROCSR ENPROTCL
EN0LKALM EN1LKALM ENALMSPT
------------------------------------------------------------------------
EXND 0 EXNODMTC (ENIP 47 73 5 95) (ENIP 47 73 5 93) $ $ CAR 1 A 1 XTERM
'COOP7W32' ALL TCP ICMP UDP $ MN NA N
