Chapter 3: EIU datafill 101
DMS-100 Family EIU User Guide TELECOM12
EN0LKALM CR
MJ
MN
NA External node no-link alarm
Enter the type of alarm to be raised if no
links are available to the external node:
• CR (critical alarm)
• MJ (major alarm)
• MN (minor alarm)
• NA (no alarm)
EN1LKALM CR
MJ
MN
NA External node one-link alarm
Enter the type of alarm to be raised if
only one link is available to the external
node.
ENALMSPT Y or N External node alarm scan points
This is a vector of up to two multiples.
Enter Y (yes) if scan points are to be
assigned to the node for alarm
purposes and datafill refinements
SCTMTYPE, SCTMNO, SCTMCTNO,
CRITSCPT, MAJSCPT, MINSCPT, and
SCCARDCD.
Otherwise, enter N (no). No further
datafill is required.
SCTMTYPE MTM or OAU Scan circuit trunk module type
Enter MTM if the scan circuit resides on
the maintenance trunk module (MTM).
Enter OAU if the scan circuit resides on
the office alarm unit (OAU).
SCTMNO 0 to 2047 Scan circuit trunk module number
Enter the trunk module (TM) of the MTM
where the scan circuit resides.
SCTMCTNO 0 to 29 Scan circuit trunk module circuit
number
Enter the circuit number on the MTM of
the scan circuit.
CRITSCPT 0 to 6 Critical alarm scan point
Enter the scan point associated with the
critical alarm for the node.
Table 26 Field descriptions for table EXNDINV for EIU datafill (continued)
Field Subfield or
refinement Entry Explanation and action
(Sheet 4 of 5)
