70 Chapter 3: EIU datafill
297-8991-910 Standard 03.01 August 1999
LIUNO 0 to 511 Link interface unit number
Enter the number assigned to the EIU.
LOCATION The actual physical location of the EIU.
This field identifies the shelf and slot
number where the EIU is located
LOCATION see subfields Location
Enter the location of the EIU on the host
link interface module.
This field consists of subfields CTRL,
SHELFNUM, and LIUSLOT.
CTRL see subfield Control information
This field consists of subfield
CONTROL.
CONTROL LIM or MS Controlling host entity
Enter MS if the host is a message
switch and datafill subfields MSCARD
and MSPORT.
Enter LIM if the controlling host is a link
interface module and datafill field
LIMNUM.
MSCARD 5 to 23 Message switch card
If the entry in field CONTROL is MS,
enter the message switch card number.
Any entries outside the range indicated
for this field are invalid.
MSPORT 0 to 3 Message switch port
If the entry in field CONTROL is MS,
enter the message switch port number.
LIMNUM 0 to 16 Link interface module number
If the entry in field CONTROL is LIM,
enter the host LIM number on which the
LIU resides.
Otherwise, leave this field blank.
SHELFNUM 0 to 3 Shelf number
Enter the shelf number, at the host LIM,
on which the EIU is located.
Table 11 Field descriptions for table LIUINV for EIU datafill (continued)
Field Subfield or
refinement Entry Explanation and action
(Sheet 2 of 4)
