Chapter 3: EIU datafill 79
DMS-100 Family EIU User Guide TELECOM12
Datafill sequence and implications
The following tables must be datafilled before table IPROUTER:
• PMLOADS
• LIUINV
• IPNETWRK
Before entering data in table IPROUTER, Nortel Networks recommends to
place the default EIU in the off-line state.
Datafill
Table 13 lists the fields and value ranges used to datafill an EIU in table
IPROUTER.
While table 13 provides all the information you need to datafill for EIUs,
complete information on table IPROUTER is in DMS-100 Translations Guide,
297-xxxx-350.
Table 13 Field descriptions for table IPROUTER for EIU datafill
Field Subfield or
refinement Entry Explanation and action
RKEY 0 to 63 Router key
Enter the identification number of the IP
router. This is the key into the table.
ROUTER see subfields Router
This field consists of subfields
WORD_EIU and EIU_RNG.
WORD_EIU EIU Ethernet interface unit
Enter EIU (Ethernet interface unit).
Entries outside this range are invalid.
EIU_RNG 0 to 750 Ethernet interface unit range
Enter the specific EIU to be accessed
for the router index.
SNIPADR table of 4 digits
(0 to 255) Supernode-side Internet Protocol
address
Enter the SuperNode-side IP address.
ETHIPADR table of 4 digits
(0 to 255) Ethernet-side Internet Protocol address
Enter the Ethernet-side IP address.
(Sheet 1 of 2)
