Cabletron Systems DMS-100 User Manual
Page 48
48 Chapter 2: EIU messaging protocols
297-8991-910 Standard 03.01 August 1999
Figure 12
SuperNode TCP/IP message flow
Applications
TCP/UDP
IP
FTS
DMS-core
Applications
TCP/UDP
IP
FTS
File processor
DMS-bus
Applications
TCP/UDP
IP
FTS
EIU
Ethernet
Ethernet LAN
Applications
TCP
IP
Ethernet
Workstation
EIU as router
Inter-host connections
