92 Chapter 3: EIU datafill
297-8991-910 Standard 03.01 August 1999
OPTION see subfield Option
This field consists of subfield SNNODE.
SNNODE AP,
APU,
CM,
EIU,
ELIU,
FP,
or
MS SuperNode node
Enter the name of the SuperNode node.
The node must first be datafilled in its
inventory table. For example, FP must
be datafilled in table APINV. Up to eight
nodes can be entered. If less than eight
are required, end the list with a $ (dollar
sign).
Enter AP (application processor) and
datafill refinement SMNINDEX.
Enter APU and datafill refinement
APUINDEX.
Enter CM and go to refinement
TXCAPCT.
Enter EIU and datafill refinement
EIUINDEX.
Enter ELIU and datafill refinement
ELIUINDEX.
Enter FP (file processor) and datafill
refinement SMNINDEX.
Enter MS (message switch) and datafill
refinement MSINDEX.
SMNINDEX 0 to 99 Synchronized and matched node index
If the entry in field SNNODE is AP or
FP, enter the synchronized and
matched node (SMN) index.
Go to refinement TXCAPCT.
APUINDEX 0 to 750 Application processor unit index
If the entry in field SNNODE is APU,
enter the APU index.
Go to refinement TXCAPCT.
Table 22 Field descriptions for table IPTHRON for EIU datafill (continued)
Field Subfield or
refinement Entry Explanation and action
(Sheet 2 of 3)
