NX-590NE Internet Interface Installation Manual 23
Segment 1
1. Reserved
2. Interface configuration message
3. Reserved
4. Zone name request
5. One zone status message
6. 16 zone snapshot message
7. One partition message
8. Eight partition snapshot message
Segment 2
1. System status message
2. Send X10 message
3. Log event request
4. Send keypad text command
5. Keypad terminal mode request
6. Keypad tone broadcast
7. Reserved
8. Reserved
Segment 3
1. Program data request
2. Program data command
3. User information request with PIN
4. User information request without PIN
5. Set user code command with PIN
6. Set user code command without PIN
7. Set user authorization command with PIN
8. Set user authorization without PIN
Segment 4
1. RF transmission request
2. Clock/calendar request
3. Store communication event request
4. Set clock/calendar command
5. Primary keypad function with PIN
6. Primary keypad function without PIN
7. Secondary keypad function
8. Zone bypass toggle
Location 91 - Keypad address for automation text
retrieval
Location 91 has one segment of numerical data. Use this location to program the
address of the keypad used for automation text retrieval. The default is 192.
Table 6 below shows the address options.
Table 6: Location 4 LCD keypad addresses
Keypad Part 1 Part 2 Part 3 Part 4 Part 5 Part 6 Part 7 Part 8
1 192
(default) 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
