will show on the bottom line of the display. The top line will display the current
location and segment number.

You can now use the five function keys, as well as the Up and Down Arrow keys, to
edit the message prior to saving it back to the location storage. An underscore in
the display indicates the current cursor location. To move the cursor to the right,
press the * key. To move the cursor to the left, press the Cancel key. To change the
character at the current cursor location, press the Up or Down Arrow key until the
desired character displays. An alternative method is to enter the two -digit number in
Table 4 below that corresponds to the desired character. To accept this character,
press the * key. The character will remain and the cursor will advance one space to
the right. To insert spaces, press Stay. To delete characters, press Chime.

Using an LCD keypad

Use the same steps to prog

ram using an LCD keypad as outlined in “Using an

LED keypad

” on page 10. The only difference is that the LCD keypad will prompt

you for the data required. When you are in programming mode and not in a
location, the number in parentheses is the location you previously changed. For
example, if the display reads Enter location, then # (2), the system is
telling you that Location 2 was the last location you programmed. In feature
selection data, the numbers of the enabled features are displayed. The features
not enabled will include a hyphen (-).

Table 4 below shows the two-digit code for the LCD keypad characters.

Table 4: Code numbers for keys

Code/Key

“

[

(



)

]

[]

‘

{
