NX-590NE Internet Interface Installation Manual
15
5 to 7. Reserved.
8. Enable polling to TCP/IP receivers (poll every period of less than five minutes).
Segment 3 Reserved
Segment 4
1. Enable SMTP e-mail authentication
2. Enable Telnet
3. Reserved
4. Enable browser
Segment 5 to 7 Reserved
Segment 8 - AUX COM Fail, for loss of polling only.
Location 1
– Partitions reporting via TCP/IP to receiver 1
Location 1 has 16 segments of feature selection data. Use this location to
program the partitions that should be included when reporting over the Network.
If you wish to exclude any partition from reporting, turn off the LED corresponding
to that particular partition (1 = Partition 1, 2 = Partition 2, etc.) and no event from
that partition will report via the network regardless of what is programmed
elsewhere. Table 5 below describes the types of reports found in Segments 1 to
16.
Table 5: Partitions
Segmen
t
Reports
Segment Reports
1
Alarms and restores
9
Tampers
2
Open/close
10
Short circuit and ground fault
3
Bypass
11
Sensor lost
4
Zone trouble
12
Sensor low battery
5
Power trouble (AC failure or low
battery)
13
Expander trouble
6
Siren and telephone fault
14
Failure to communicate
7
Test reports
15
Zone activity monitor
8
Program, download, and log full
16
Reserved
