Cordless Roll-Up 5
1. Disconnect the transducer and interface cable from the Cordless Roll-Up and the
computer. Remove all material from the tablet.
2. Grasp the housing firmly with both hands and roll it toward the opposite side of the
tablet. The housing and the printing on the digitizer surface must be on the inside
of the roll. The roll diameter should be just smaller than the inside diameter of the
factory-supplied shipping tube. When correctly rolled, only the digitizer’s black back
will be exposed.
3. Insert the rolled digitizer into the shipping tube and allow it to fully unroll against
the inside of the tube. Place the factory-supplied insert into the center of the rolled
digitizer for support.
4. Place the accessories in the accessory case and put it inside the hollow insert. Set
the factory-supplied end caps on the tube to seal it. Place the tube in the optional
Deluxe Travel Bag (optional).
NOTE: The Deluxe Travel Bag is intended to be used only in conjunction with the factory-
supplied heavy gauge cardboard tube, insert and end caps. The Deluxe Travel Bag does
not provide complete protection if used alone. The product will be subject to damage not
covered by the warranty, if not protected by the tube, insert and end caps. If you have
misplaced or disposed of these items, contact GTCO CalComp by Turning Technologies
(1.866.746.3015) for replacement parts.
Installing Cordless Roll-Up
Follow the instructions below to set up the Cordless Roll-Up.
1. Select a large, flat surface on which to place the Cordless Roll-Up. Clear all items
from the surface. Please be cautious that conductive materials on, under or near
the Cordless Roll-Up may cause improper operation.
