HP LaserJet 4610n - Manual (Page 73)

Parallel configuration
The HP Color LaserJet 4610n printer supports network and parallel connections at the same
time. A parallel connection is made by connecting the printer to the computer using a
bidirectional parallel cable (IEEE-1284-C compliant) with a c-connector plugged into the
printer’s parallel port. The cable can be a maximum of 10 meters (30 feet) long.
When used to describe a parallel interface, the term bidirectional indicates that the printer is
able to both receive data from the computer and send data to the computer through the
parallel port.
Parallel port connection
1 c-connector
2 parallel port
NOTE To use the enhanced capabilities of the bidirectional parallel interface such as bidirectional
communication between the computer and printer, faster transfer of data, and automatic
configuration of printer drivers, ensure that the most recent printer driver is installed. For
more information, see
Printer drivers .
ENWW Parallel configuration 61
