Table 6-5. +VLS Command Options
Label
Primitives
Description
+VTX
+VRX
+VSP=1
0
None
DCE on-hook. Local phone connected to the line.
1
T
DCE off-hook. DCE connected to the line. Local phone provided with power to
detect hook condition.
X
X
2
L
DCE on-hook. Local phone connected to the DCE.
X
X
3
LT
DCE off-hook. Local phone connected to the line. DCE connected to the line.
X
X
4
S
Internal Speaker connected to the DCE. DCE on-hook. Local phone connected
to the line.
X
5
ST
Internal Speaker connected to the line. DCE off-hook. DCE connected to the
line. Local phone provided with power to detect hook condition.
X
X
6
M
Internal Microphone connected to the DCE. DCE on-hook. Local phone
connected to the line.
X
7
MST
Internal Microphone and Internal Speaker connected to the line. DCE off-hook.
DCE connected to the line. Local phone provided with power to detect hook
condition.
X
8
S1
External Speaker connected to the DCE. DCE on-hook. Local phone connected
to the line.
X
9
S1T
External Speaker connected to the line. DCE off-hook. DCE connected to the
line. Local phone provided with power to detect hook condition.
X
X
10
MS1T
Internal microphone and External Speaker connected to the line. DCE off-hook.
DCE connected to the line. Local phone provided with power to detect hook
condition.
X
11
M1
External Microphone connected to the DCE. DCE on-hook. Local phone
connected to the line.
X
12
M1ST
External Microphone and Internal Speaker connected to the line. DCE off-hook.
DCE connected to the line. Local phone provided with power to detect hook
condition.
X
13
M1S1T
External Microphone and External Speaker connected to the line. DCE off-hook.
DCE connected to the line. Local phone provided with power to detect hook
condition.
X
14
H
External Microphone and Speaker combination (handset or headset) connected
to the DCE. DCE on-hook. Local phone connected to the line.
X
X
15
HT
External Microphone and Speaker combination (handset or headset) connected
to the line. DCE off-hook. DCE connected to the line. Local phone provided with
power to detect hook condition.
X
X
16
MS
Internal Microphone and Internal Speaker connected to DCE.
17
MS1
Internal Microphone and External Speaker connected to DCE.
18
M1S
External Microphone and Internal Speaker connected to DCE.
19
M1S1
External Microphone and External Speaker connected to DCE.
Primitives (Column 2):
L
Local Phone.
T
Telephone Line.
M
Internal Microphone.
M1
External Microphone.
S
Internal Speaker.
S1
External Speaker.
H
External Microphone and Speaker combination (handset or headset).
Notes:
1. All label options in this table may not be supported by the product; see +VLS command.
