19. Operations in “MGR” Mode
This chapter describes operations to be performed in the “MGR” position of
the Control Lock, which the Store Manager can access using the MGR or MA
key.
Items programmed to require Manager Intervention
During daily sale entry operations, the cashier may call for Manager Intervention. The following is
the operation flow of Manager Intervention.
1)
During operations, the cashier comes across an item that requires Manager Intervention.
The cashier, already Informed of it, may immediately call for Manager Intervention. Or the
cashier, without knowing of it, attempts the operation, and an error results, clears the error by
the [C] key, and then calls for Manager Intervention.
i
2) The Store Manager goes to the cashier counter with the MGR or MA key.
3)
The cashier explains what kind of operation is to be entered, and removes the
REG
key from
the Control Lock at the
“REG”
position.
4) The Store Manager insert the
MGR
or
MA
key and turns it to the
“MGR”
position.
5) The cashier operates the required item.
6) The Store Manager returns the
MGR
or
MA
key to the
‘REG”
position and pulls it out.
7)
The cashier returns the REG key to the “REG” key position and continues sale entry
operations.
The following are the tables of the keys and operations that are programmable with Manager
Intervention. Fill in the tables by marking in the “Not required” or “Required” column of each
item, referring to the System Option Setting Addresses (Chapter 22). Or only to read the set
status of each Address and Bit, refer to Chapter 23.
Program Data Verification.
Keys and Manager Intervention Status
KEY
MGR Position
Reference
(See Chapter
“22.
System Option Setting”.)
Not required
Required
[RTN MDSE]
Address 5 - BH 1
[PO]
Address 5 - Bit 2
[DOLL DISC] and [ % - ]
Address 5 - Bit 3
