■ Using the ENTER Function

1

Press the microphone key that has been

programmed with the ENTER function
{page 35}.

• The frequency template is displayed in the

format ---------- representing the 1 MHz
digit down to the 100 Hz digit.

7 AUXILIARY FUNCTIONS

A VFO

N

Ij zi...................................

/ Jf

. .

SI 3 5 7 9 ^

FM

2 4 6 6 10

J

2 Input the desired frequency sequentially starting

with the 1 MHz digit using the microphone

DTMF numeric keypad.

• After the 100 Hz digit is entered, input mode

automatically ends.

• Pressing the ENTER function key during

input mode causes a zero to be entered in
subsequent digits not entered yet.

PROGRAMMABLE FUNCTION (PF) BUHON

The Front Panel has a Programmable Function button
in the upper right corner of the panel. This button is
similar to the microphone PF keys since it can be
assigned a function by the operator. The same
functions that can be assigned to the microphone PF
keys can also be assigned to the Front Panel PF

button. Refer to "REMOTE FUNCTIONS USING THE

MICROPHONE (page 35}".

1

Select Menu B, No. 74 (page 14}.

2 Select the number that corresponds to the function

that you want to assign to the PF key (page 35}.

• Press [F.LOCK] or microphone [UP] to

increment the function number.

• Press [LOW] or microphone [OWN] to

decrement the function number.

• The function ranges are as follows:

00-08:

Menu A

20-42:

Front Panel keys

50-78

Menu B

80-87:

Special Functions

99:

No assigned function

• The default is Voice Synthesizer (85).

3 Press [F] or [CLR] to complete the setting.

LOCK FUNCTIONS

Occasionally, you may want to lock the buttons, keys
and the Tuning controls to prevent accidentally
changing any transceiver settings. This transceiver

has several lock functions to provide maximum

flexibility.

Frequency Lock

Enabling the Frequency Lock function locks the

following:

Main Tuning control
Alternate Tuning control

MR button

A/B button

MHz button
M.IN button
M>V button
SCAN button
CLR button
SHIFT button
TONE button

REV button

AUTO/FM button

SSB/CW button
CALL button
Microphone UP/DWN
Microphone PF2/PF3/PF4 keys

The following controls and buttons are not affected
by enabling Frequency Lock:

VOL/SQL controls

RIT/IF SHIFT controls
F button
RIT button
LOW button
PROC button

AlP button

NB button
PF button
Microphone PTT switch
Microphone PF1 key
Microphone DTMF keypad
Microphone Lock switch

Activate Frequency Lock with the following

procedure:

Press [F.LOCK].

• "F.LOCK" appears when Frequency Lock is

ON.

• Each press of [F.LOCK] toggles the function

ON and OFF.

c

F. LOCK

A VFO

\

1./ 7/ o

7/ n c o

FM

1

Jf

/.

Jf

/

J/. Cl

S I 3 s

7 9

20

40dB

V____

2 4

5

8

10

J

36
