GETTING ACQUAINTED
Ф Ф ( 6 ) 0 (8) (|) ® ® ®
1Ф-
MENU
★ М. СН
F.LOCK MHz А VFO В---------------- + TONE REV PROC AlP
п п О О 0*0 о ‘О о ^ г7п
и. и. LhU. LhD. О, ~Ш
BUSY I S I 3 5 7 / , , , ------
l l l l l l l l l l l l i l V l I l l l l l l l l l l l l l l L O W
R F 2 4 / 6 8 ■ ' О /
I on airi
DTSS CTCss co
M. SCR /PRG SCAN
7 i _5
-29.
^ STAR
Appears when the selected Page code is locked-out.
@ Meter
In Receive, acts as a Peak Hold S-meter to indicate
the signal strength of received signals from S1 to 40
dB over S9. In Transmit, acts as a Peak Hold RF
meter to indicate approximate transmit output power
on a scale from 1 to 10. The peak hold characteristic
can be disabled by menu selection if desired. The S-
meter is used for setting the squelch threshold of the
S-meter Squelch function.
Appears when Low transmit output power is selected.
When "LOW" is not visible. High output power is
selected.
® DTSS
Appears when the Dual Tone Squelch System is ON
(FM mode only).
© CTCSS
Appears when the Continuous Tone Coded Squelch
System is ON (FM mode only) when the CTCSS unit
is installed.
(g) CO
Appears when Carrier-operated Scan Resume is ON.
When not visible. Time-operated Scan Resume is in
effect.
(g) CW
Appears when the CW mode is selected by pressing
[SSB/CW].
(g M.SCR
Appears when Memory Scroll is selected by pressing
[M.IN].
(g) PRG
Appears when memory channel 99 is selected or
during Program Scan.
(g SCAN
Appears during Program Scan or Memory Scan.
(g TOT
Appears when the Time-out Timer function is ON.
® Digital frequency display
Displays the transmit and receive frequencies. Also
displays menus while accessing Menu Setup or
DTSS/Page Code Select, and minutes/seconds for
Tone Alert.
