MICROPROCESSOR MEMORY BACKUP
This transceiver uses a lithium battery to retain the
user-specified memory items. Switching the power
OFF will not erase the Menu Setups or memory
channels. Lithium battery life is approximately 5
years.
If you find the transceiver powers-up with default
settings, and channel and VFO data is erased, have
the lithium battery replaced. Contact an authorized
KENWOOD Service Facility or dealer.
MEMORY CHANNEL DATA
This transceiver has numerous memory channels for
different purposes as follows:
• 50 simplex channels
• 49 split-frequency channels
• 1 Scan Limits channel
• 1 Call channel
Channel
No.
Channel
Purpose
00 to 49 Simplex Use for simplex or repeater
communications.
50 to 98 Split-
Frequency
Use for simplex, repeater, or half­
duplex communications (different
TX/RX frequencies).
99 Scan
Limits
Stores the lower frequency limit
and the upper frequency limit for
tuning in VFO mode or for
Program Scan.
Call
Channel
Quick
Recall
Use as a quick recall simplex
memory channel.
The following can be stored in memory:
__ Parameter
Chans.
0Cit0 49
Chans.
50 to 98
Chan.
99
Call
ChannsI
Receive frequency Yes Yes Yes Yes
Transmit frequency N/A Yes N/A N/A
Lower and upper
Scan frequency
No No Yes No
Modulation mode Yes Yes Yes Yes
Tone (CTCSS)
frequency
Yes Yes Yes Yes
Tone/CTCSS
status (ON/OFF)
Yes Yes Yes Yes
DTSS code Yes Yes Yes No
Offset status (+/-) Yes No Yes Yes
Reverse(ON/OFF) Yes No Yes Yes
AlP (ON/OFF) Yes Yes Yes Yes
Lock-out (ON/OFF) Yes Yes Yes No
Note:
♦
When changing Lock-out status after recalling any memory
channel, the newly selected status is stored automatically in
that memory channel.
♦
When changing stored data other than the lower frequency and
upper frequency limits after recalling the Scan Limits channel
99, the new data is stored automatically in that channel.
MEMORY CHANNEL STORAGE
SIMPLEX CHANNEL STORAGE
Store the same transmit and receive frequency in any
memory channel from 00 to 49 with this procedure.
1 Select a frequency, a modulation mode, and other
data (as required) using VFO A.
A VFO
U Zi
zt
c Zl
C n FM
\
1
Jf
c, o
S t 3 5 7 9 2°
2 4 6 8
c
40dB
to
Jf.
U
J
2 Press [M.IN].
• The last memory channel selected appears.
c
M. CH
n
U L
U zt
1
Jf
n o
LI. Cl
O Zl n
O
Jf.
LI
\
USB
s
V____________
t 3 s
2 4
7 9 20
6 ' 8
40dB
10 M. SCR j
3 Select a memory channel using the
Alternate Tuning control or microphone
[UP]/[DWN].
• Pressing [MHz] allows you to select from empty
memory channels only. Pressing [MHz] again
cancels this function.
4 Press [M.IN] again.
• The data from VFO A is stored in the selected
memory channel, and the transceiver returns to
VFO mode.
Note: Pressing [M.IN] overwrites new data on any previous data
in that channel.
Yes: Can be stored
No: Cannot be stored
N/A: Not applicable
