4.2 Analyze Measurement Data

All measurements that have been acquired with

this software were saved under a certain name.

Directly after the import of the measuring data,

the measuring curve will be indicated in the chart

range, all analysis tables are closed and can be

opened if necessary. They can be searched for

and opened in the database pane at any later point

of time. If a measurement is not already visible,

please go to the database pane and double click

the desired measurement.

4.2.1 The Chart area

The following things are indicated:

• the temperature curves of all sensors; individual

curves can be indicated or hidden with the button

in the sensor window.

Pull the mouse over the curves, and the program

shows the data values of the time and temperature

axes at the lower edge of screen.

If you would like to expand a certain section of the

measurement you can either:

Chart area
