Set Curing Conditions
2. Enter the probe names and select the color for
display
3. Enter the sampling rate, trigger information and
measurement duration
4. Load a picture (most graphic formats like bmp,
gif, jpeg are supported) and position the sensors
by dragging the numbered squares from the upper
left corner of the picture
Step 2:
Connect the temp-gard to the PC or insert the
USB-Stick. Then activate the Instrument tab, make
sure you have selected the appropriate connection
settings and press
Select the newly created organizer in the upcoming
dialog and press OK.
The Organizer will now be transferred to the
USB stick or the connected device and can be
used for new measurements. Already existing
QC-procedures can likewise be selected and be
transferred together.
2.2 Set Curing Conditions
The paint makers recommend temperature/
time conditions will be compared to the actual
temperature/time during the heating process.
temp-chart allows you to define and modify
objects of type „Curing Condition“ where you
can enter the supplied target values. These
values are then used in the analysis pane and in
the protocols temperature defaults, Cure index
and Peak/Threshold/Slope. On the basis of the
equivalence time the Cure index is computed.
