ALTANA Temp-Chart User Manual

Page 21

2.4 Set Tolerance Curve

A Tolerance Curve is a collection of reference

values the program will take as a basis for creating

the tolerance curve shown in the chart page

facilitating the evaluation of measurements.
You should create a Tolerance Curve once. It can

then be assigned to different measurements or

added to the QC-Procedure:
• Select Objects/Oven Specifications in the

Select Tolerance Curves database pane

• Right click and Create a new object
• Name the object with a suitable description and

press the „Save As“ button

• Enter the tolerance settings

• The Name of the Tolerance Curve can be freely

chosen.

• The Frame Color and Background choices

determine the colors used in the chart page.

Please select None in the Background field if

you want to show only the outline.

Set Tolerance Curve
