9
Menu Instrument
SRAM/USB Check to use an USB-Stick (temp-
Stick gard 6p or temp-gard 12p) or a
SRAM card from a temp-gard 8p
1.3.2 Section temp-gard
The section temp-gard contains the operation
commands for the selected instrument:
Transfer Data Use this command to
import a measurement from
the selected device.
Send Organizer Use this command to pre
pare the selected device for
a new measurement
Delete Data on Use this command to delete
SRAM/USB Stick data files from an USB
Stick or a SRAM card
1.3.3 Section gradient-oven
The section gradient-oven contains the operation
command for a BYK gradient oven:
gradient-oven Sends temperature curves
to the gradient-oven and
controls the data flow of the
instrument
Attach the gradient-oven and select from its Main
Menue:
• Point 3 byko-track or
• Point 4 byko-track 2.
In the Software temp chart:
• load the measurement curve
• select gradient-oven in the Instrument tab
• select probes
