APPENDIX A

TEMPERATURE CONTROLLER INFORMATION

MODBUS Communication information (Eurotherm 2408)

NOTE:

The Eurotherm 2400 Controller supports the MODBUS RTU mode of
transmission. The default settings are as follows: 9600 Baud Rate,
one start bit, eight data bits, one stop bit, & no parity bit.

IMPORTANT NOTE:

All Modbus addresses specified in this manual are written generically
in decimal format. However, many Building Automation Systems
utilize another form of addressing where: 40001 is added to the
generic address for a Holding Register address And 30001 is added
to the generic address for an Input Register address.

Check the addressing scheme being used by the BAS interfaced to
the XPC Gateway.

EUROTHERM SERIES 2400 CONTROLLER MODBUS POINTS

MODBUS

Data Addr

(BAS)

MODBUS

Data Addr

(Hex.)

MODBUS

Data Addr

(Dec.)

Menu

Item

Menu Item

Description

Units &

Range

Default/Comments

Register

Type

Ref. 1

Comm.

Guide

30006

0x0005

5

w.SP

Setpoint

40-205°F 140°F, Address to read

value

Read

Only

5-4

40025

0x0018

24

SP 1

Setpoint

(local or

internal)

40-205°F

140°F, Address to

change value

Write

5-11

30002

0x0001

1

Top

Value

Outlet Temp 40-205°F

Same value as front

display

Read

Only

5-3

30134

0x0085

133

LoGH

Peak Temp

40-205°F Resets on Power Loss

Read

Only

5-15

30136

0x0087

135

LoGA

Average

Temp

40-205°F Resets on Power Loss

Read

Only

5-15

30135

0x0086

134

LoGL

Low Temp

40-205°F Resets on Power Loss

Read

Only

5-15

30075

(status)

30014 (set)

0x004A

0x000D

13 (set)

74 (status,

0 = safe

1 = alarm)

AL 1

Over Temp

Alarm

40-205°F

20°F above setpoint;

Alarm Type 17:

Deviation High

Read

Only

5-7

5-20

30075

(status)

30015 (set)

0x000E

0x004A

14 (set)

74 (status,

0 = safe

1= alarm)

AL 2

(FSH)

Full Scale

High Alarm

205°F

205 ° F

Alarm Type 2: Full Scale

High

Read

Only

5-7

5-20

30259

0x0102

258

Sbr

Feedback

Sensor Break

Status:

0:Good

1:Failed

Denotes Feedback

Sensor Failure/Open

Circuit

Read

Only

5-18

30290

0x0121

289

Li 1

Feedback

Sensor Temp

40-180°F

Sensor input to

controller, same as

display temp.

Read

Only

5-14

30291

0x0122

290

Li 2

Flow

GPM

Read

Only

5-14

30004

0x0003

3

OP

Control

Output Signal

%

Correlates to valve

position

Read

Only

5-4

40027

0x001A

26

RI

Remote Input

Comms

Access

Parameter

40-205°F

MODBUS Remote

Setpoint Address

Write

5-17
