ECS Control Box Assembly Parts List
CONTROL BOX ASSY.
69012-1
(STEAM/
WATER)
69012-2
(WATER/
WATER)
ITEM QTY QTY PART NO. DESCRIPTION
1 1 69011-1 CONTROL BOX (STEAM/WATER)
2 1 69011-2 CONTROL BOX (WATER/WATER)
3 1 1
SEE TABLE
A
TEMPERATURE CONTROLLER
4 1 3 64007 OVER-TEMP SWITCH/TEMP INDICATOR
5 1 1 60003 ON/OFF SWITCH
6 1 63009-1
CONTROL BOX, EXTERNAL HARNESS
(S/W)
7 1 63009-2
CONTROL BOX, EXTERNAL HARNESS
(W/W)
8 1 1 65006 POWER SUPPLY
9 1 1 65007 TERMINAL BLOCK, 4-POSITION (TB-2)
10 1 1 64011 VOLTAGE REGULATOR
11 1 1 65008 TERMINAL BLOCK, 20-POSITION (TB-1)
12 AS REQ’D AS REQ’D
SEE TABLE
B
COMMUNICATIONS BOARD
13 1 1 62004 PLUG
14 8 8 53011 LOCK WASHER, #4
15 12 12 65010 STANDOFF
16 4 4 53010 LOCK WASHER, #8
17 4 4 56012 HEX NUT, #8-32
18 2 2 56011 HEX NUT, #6-32
19 2 2 53012 LOCK WASHER, #6
20 4 4 56010 HEX NUT, #4-40
21 2 2 62002 STRAIN RELIEF
22 1 1 62003 PLUG
THE FOLLOWING ITEMS ARE NOT ILLUSTRATED IN FIGURE 8-9:
23 1 69014-1 CONTROL BOX CONNECTORS
24 1 69014-2 CONTROL BOX CONNECTORS
25 1 1 63007 AC WIRE HARNESS
26 1 63008-1 CONTROL BOX CONN. WIRE HARNESS
27 1 63008-2 CONTROL BOX CONN. WIRE HARNESS
Figure 8-9. ECS Control Box Assembly Component Locations (Sheet 5 of 6)
