Electronic Control System (ECS) and Type CXT-E Valve
1. GENERAL INFORMATION
Page 14 of 82
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 VD2: 02/28/14
OMM-0003_0D AC-105
1.4 REFERENCE DOCUMENTS
Refer to the following documents as necessary for additional information and procedures for the
applicable AERCO Heat Exchanger provided with your Electronic Control System (ECS) and CXT-E
Control Valve. In addition, if the ECS is provided with the Modbus Communication option, refer to the
referenced Eurotherm documents listed.
1.4.1 AERCO Documents
HE-104 SW1B-Plus Heat Exchanger Installation, Operation & Maintenance Manual
HE-105 WW3E Heat Exchanger Installation, Operation & Maintenance Manual
HE-106 DW-24, DW-45, DW-68 Double Wall Heat Exchanger Installation, Operation &
Maintenance Manual
HE-107 SW1A-Plus Heat Exchanger Installation, Operation & Maintenance Manual
HE-110 B-Plus II Water Wizard Heat Exchanger Installation, Operation & Maintenance
Manual
1.4.2 Eurotherm Documents – (Available at www.eurotherm.com)
HA025132 2404/2408 Installation & Operation Handbook
HA02630 Series 2000 Communications Handbook
CAUTION
DO NOT use the Actuator Linkage Frame at the top of the Control
Valve Body for leverage when installing The Control Valve. Use pipe
wrenches on the inlet and outlet hex of the Valve Body.
! !
