Electronic Control System (ECS) and Type CXT-E Valve
1. GENERAL INFORMATION
Page 12 of 82
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288 VD2: 02/28/14
OMM-0003_0D AC-105
1.3 ELECTRONIC CONTROL VALVE CXT-E
Each Control Valve is comprised of three major sections; the Valve Body, Linkage Assembly
and the Valve Actuator. The Control Valves are available in sizes ranging from 1 inch to 4
inches. An identical Actuator Assembly is used with each size Valve Body. The Linkage
Assembly used with each size Valve Body is identical, except for minor differences in the Shaft
Adapter stroke of the mechanical linkage. Figure 1-4 shows the basic dimensions for each size
AERCO Control Valve CXT-E.
It should be noted that the Control Valves used for steam flow are identical to those used for hot
(boiler) water flow.
1.3.1 Control Valve Accessories
The accessories required for use with AERCO Electronic Control Valves, Type CXT-E will
depend on the specific application. Detailed installation instructions, including typical installation
drawings are provided in the INSTALLATION Section of this manual. However, please note the
items listed below and ensure that ALL mandatory items are available:
ACCESSORY REQUIREMENT
•
Upstream Shutoff Valve - Mandatory
•
Downstream Shutoff Valve Suggested for ease of
maintenance. Required if a
Bypass Line is used.
•
Strainer and Blow-Off Valve Mandatory
•
High Side Pressure Gauge Recommended for adjustment
and maintenance
•
Low Side Pressure Gauge,
Compound Type for steam flow Recommended for adjustment
and maintenance.
If any of these items have been furnished by AERCO with the Control Valve, the
necessary drawings and/or instructions should be included with the shipment.
