2. UNPACKING THE VISCOMETER
The viscometer is a precision instrument. Unpack the viscometer carefully. Keep the packing
material to be used for transporting the viscometer in the future.
2-1 Part names for the SV-A series (Stand type)
*
The illustration below is after assembling.
Lever
Guides
Sample cup
Table
knob
Main unit
Display unit
Display
Keys
Sensor unit
Sensor protective
cover
Cap
Supporting
post
Surface locator
plate
AC adapter jack
RS-232C serial interface
Connection
cable jack
Display unit
rear side
Right and left
direction
knob
Back and forth
direction
knob
(Height direction)
Serial number
Serial number
Leveling foot
Reference card
Temperature sensor
Grip
Protector
Sensor
plate
SV-1A
SV-10A/SV-100A
S/N1234
5164
Temperature sensor
Sensor
plate
