67
Printing format example (3)
Function setting
( √=Output Blank=No output)
5-at 1
Measurement
elapsed time
√
5-td 1 Date/time √
Remarks
Device ID
information
5-ed 0
Signature
(*) The displaying order of the date (YMD/DMY/MDY) depends on the setting of "Date/Time
(Cladj)".
Printing format example (4)
Function setting
( √=Output Blank=No output)
5-at 1
Measurement
elapsed time
√
5-td 0 Date/time
Remarks
Device ID
information
5-ed 0
Signature
Printing format example (5)
Function setting
( √=Output Blank=No output)
5-at 0
Measurement
elapsed time
5-td 0 Date/time
Remarks
Device ID
information
5-ed 0
Signature
9-4-3 CSV Format
Appropriate when a personal computer is used to collect data. Measurement values are output in
comma separated format.
With "5-td" setting, the date and time can be added to the measurement data.
When a comma is selected as the decimal point by "pnt 1", a semicolon ";" is used as a data
separator.
With CSV format selected, the viscosity value and the temperature are output using the internal
resolution.
The relation between the measuring unit and the internal resolution is as follows:
Viscosity Temperature
Model
m mPa･s Pa･s c cP P °Ｃ °Ｆ
SV-1A/SV-1H
SV-10A/SV-10H
0.01 0.0001 0.01 0.0001
Internal
resolution SV-100A
SV-100H
- 0.01 - 0.1
0.01 0.01
