73

SV-10A/SV-10H output format example

Viscosity

/

Temper-

ature

Display

Output format example

Remarks

L

LLLL

mPa・s

+00000.00,mPa s,+025.67,C

Zeroes are output for below measuring
range error.

0.30 mPa・s

+00000.30,mPa s,+025.67,C

10.0 mPa・s

+00010.00,mPa s,+025.67,C

100 mPa・s

+00100.00,mPa s,+025.67,C

1.00 Pa・s

+01000.00,mPa s,+025.67,C

For 1000 mPa

⋅s or greater, the displayed unit

is Pa

⋅s, but the output unit remains mPa⋅s.

M

mPa・s

/

°C

H Pa・s

+12000.00,mPa s,+025.67,C

12000 is output for above measuring
range error.

L Pa・s

+000.0000, Pa s,+051.23,F

Zeroes are output for below measuring
range error.

0.0003 Pa・s

+000.0003, Pa s,+051.23,F

0.0100 Pa・s

+000.0100, Pa s,+051.23,F

0.100 Pa・s

+000.1000, Pa s,+051.23,F

1.00 Pa・s

+001.0000, Pa s,+051.23,F

Pa・s

/

°F

H Pa・s

+012.0000, Pa

,+051.23,F

12 is output for above measuring range error.

L cP

+000.0000, cP

,+025.67,C

Zeroes are output for below measuring
range error.

0.30 cP

+00000.30, cP

,+025.67,C

10.0 cP

+00010.00, cP

,+025.67,C

100

cP

+00100.00, cP

,+025.67,C

10.0 P

+01000.00, cP

,+025.67,C

For 1000 cP or greater, the displayed
unit is P, but the output unit remains cP.

C

cP

/

°C

H P

+12000.00, cP

,+025.67,C

12000 is output for above measuring
range error.

L

P

+000.0000,

P

,+051.23,F

Zeroes are output for below measuring
range error.

0.0030 P

+000.0030,

P

,+051.23,F

0.100 P

+000.1000,

P

,+051.23,F

1.00 P

+001.0000,

P

,+051.23,F

10.0 P

+010.0000,

P

,+051.23,F

P

/

°F

H P

+120.0000,

P

,+051.23,F

120 is output for above measuring range error.

: Space (ASC 20h)

SV-100A/SV-100H output format example

Viscosity

/

Temper-

ature

Display

Output format example

Remarks

L Pa・s

+0000.000, Pa s,+025.67,C

Zeroes are output for below measuring
range error.

1.00 Pa・s

+00001.00, Pa s,+025.67,C

10.0 Pa・s

+00010.00, Pa s,+025.67,C

Pa・s

/

°C

H Pa・s

+00120.00, Pa

,+025.67,C

120 is output for above measuring range
error.

L P

+000000.0,

P

,+051.23,F

Zeroes are output for below measuring
range error.

10.0 P

+000010.0,

P

,+051.23,F

100 P

+000100.0,

P

,+051.23,F

P

/

°F

H P

+001200.0,

P

,+051.23,F

1200 is output for above measuring range error.

: Space (ASC 20h)
