15
4 Confirm that the stand’s mounting holes and the
display’s mounting holes match up. Secure both
sides of the display with the knobs.
5 Insert the AC adapter plug into the AC adapter
jack located on the rear side of the display unit.
Insert the other end of the AC adapter plug into
an electrical outlet.
Note
Confirm that the adapter type is correct for the
local voltage and power receptacle type.
AC adapter cable
Connection cable
from the main unit
(Connect as shown) Display unit
rear side
Serial number
Knob for securing
the display
Stand
Display
Knob for
securing
the display
