17

Screws

Base

Supporting post

6 Press the START or HOLD key to display

Htype .

7 Press the PRINT key to store the setting.

After the viscometer displays end , it display the

next item of the function setting.

8 Press the STOP key to return to the standby mode.

If you need other functions of the portable type, refer to

“9. FUNCTION SETTING”.

3-2 Changing from SV-H (Portable type) to SV-A (Stand type)

In the case that you have purchased an SV-H series (portable type), and you need to use it with the

stand set, prepare the following accessories and make the following changes.

- AX-SV-51 Stand set

- AX-SV-53-EX Software set

- AX-SV-54 Sample cup set (10 mL/13 mL/45 mL)

- AX-SV-55 Sample cup set (2 mL) Only for SV-1A/SV-1H


Note: When removing or tightening the screws located on the rear side of the sensor unit’s

handle, use the screwdriver that is provided with the viscometer.

1 Remove the two screws from the bottom of

the supporting post. Install the supporting

post of the stand set onto the base. From the

underside of the base, secure the post using

the two screws previously removed.

Next item of

function setting

(Standby mode)

or

From the previous page
