Output
Sensor amplifier ID numbers 01 to 10 are assigned to bits 0 to 9, respectively.
For details of communication methods, see "Reading an output from a sensor
amplifier" (page 3-14).
3-output mode
IN area
n: The first device number assigned to the DL-DN1
The device assignments are the same for all 3-output modes including extended
modes.
All 5-output modes
IN area
n: The first device number assigned to the DL-DN1
The device assignments are the same for all 5-output modes including extended
modes.
Current value (instantaneous flow rate)
The assigned positions for current values vary with different operating modes.
For details of communication methods, see "Reading current values
(instantaneous flow rate) from sensor amplifiers" (page 3-15).
"3-output + current value" mode
Device
(DEC)
Name
Bit 7 Bit 6 ··· Bit 1 Bit 0
Bit 15 Bit 14 ··· Bit 9 Bit 8
n+1 Output 1
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
n+2 Output 2
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
n+3 Output 3
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
Device
(DEC)
Name
Bit 7 Bit 6 ··· Bit 1 Bit 0
Bit 15 Bit 14 ··· Bit 9 Bit 8
n+1 Output 1
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
n+2 Output 2
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
n+3 Output 3
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
n+4 (Not used)
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
n+5 (Not used)
ID08 ID07 ··· ID02 ID01
Reserved ID15 ··· ID10 ID09
