CHAPTER 1 - OVERVIEW
1-3
1. Metric Poll
2. Averages (1-255)
3. WAVERSAVER
®
4. Calibration Type (C2
®
or Hard
Calibration) - Not configurable,
Read Only
5. Span Weight
6. Set Point Values
a. Mode
b. Preact
c. Deadband
NOTE: WAVERSAVER
®
and C2
®
are registered trade-
marks of Hardy Instruments, Inc.
Configuration data is stored in an
EEprom. I/O slave messaging is polled.
The weight module supports two TTL
levels out to relays for use as set points.
A bit is supplied when the set point is
reached.
NOTE: Hardy Instruments does not supply the set point
module.
WAVERSAVER
®
Typically, mechanical noise is present in
forces larger than the weight forces try-
ing to be detected. The HI 200DNWM
weigh module is fitted with WAVER-
SAVER
®
technology which eliminates
the effects of vibratory forces present in
all industrial weight control and mea-
surement applications. By eliminating
the factor of vibratory forces the control-
ler is capable of identifying the actual
weight data. WAVERSAVER
®
enables
