CHAPTER 7 - OPERATION
7-3
Module Status
(DS2)
Table 7-2: MODULE STATUS (DS2)
OPERATION
AND ON LINE
NOT CON-
NECTED FLASHING
GREEN ON LINE NORMAL CONDITION NO CONNECTIONS
Dup_MAC_ID PASSED & ON LINE, NO CONNECTIONS
TO OTHER NODES.
CRITICAL
FAULT OR LINK
FAILURE RED UNRECOVERABLE FAULT (MAY NEED REPLACING)
FAILED COMMUICATIONS (DUPLICATE Mac ID OR BUS
OFF)
STATE LED INDICATION
Table 7-1: NETWORK STATUS (DS1)
STATE LED INDICATION
NOT POWERED/
NOT ON LINE OFF DEVICE IS NOT ON LINE
1. NO POWER APPLIED
OPERATIONAL GREEN NORMAL CONDITION
MINOR FAULT
AND/OR CON-
NECTION TIME-
OUT FLASHING
RED RECOVERABLE FAULT A/D ERROR, USUALLY
CAUSED BY BAD CONNECTION TO LOAD CELLS
LOAD CELL OUT OF RANGE. SENSE LINES MUST BE
INSTALLED. (See Chapter 3, Page 3-10 for more information)
CRITICAL
FAULT OR LINK
FAILURE RED UNRECOVERABLE FAULT (Board MAY NEED REPLAC-
ING)
FAILURE IN A-D.
