HI 200DNWM MANUAL
4-2
ladder logic written that refers to the 4
bytes of input polled data needs to be
changed and any reference to the output
data also needs to be reviewed and possi-
ble modified.
DIP Switch (S1) Con-
figuration Configuring the DIP switch sets the fol-
lowing:
1. Baud Rate
2. Node Address
DIP Switch Loca-
tion The DIP Switch is located between THE
BUTTON and the J3 Header. (See Fig. 4-
1 & 4-2)
Configuring the
Baud Rate Refer to Table 4-1 to configure the baud
rate. 0 = OFF, 1 = ON (* is the default
setting)
Baud Rate S1-7 S1-8
125 kbps* OFF OFF
250 kbps OFF ON
500 kbps ON OFF
500 kbps ON ON
Table 4-1: Baud Rate
