HI 200DNWM MANUAL
5-12
using. Be sure to read the DeviceNet Man-
ager instructions first before setting.
Setpoint Mode
Parameters
About
Setpoint
Mode
Parameter The Setpoint mode parameter is a bit
encoded byte that affects the behavior of the
setpoint.
Entering
Setpoint
Mode
Parameters
Bit Description
Bit 7 Setpoint On/Off. Set to 1 to activate the setpoint, set
to 0 to disable it.
Bit 6 Set to 1 to output 0 volts (Force Relay Off)
Bit 5 Set to 1 to output 5 volts (Force Relay On)
Bit 1 Set to 0 for a gain in weight setpoint, set to 1 for a loss
in weight setpoint.
Bit 0 Set to 1 for a setpoint based on Net weight, or to 0 for
a setpoint based on gross weight.
