Brookfield Engineering Labs., Inc. page 44 Manual No. M14-223
III.8.6 Export Options
The first icon is the SD card. This is for use by Brookfield service personnel.
If a USB memory stick is connected, the next icon is a folder label that will say, “USBSTICK1”. Double
click on the folder to view the data files that are stored on the memory stick.
The next icon is a folder that is called, “DATA2”, and contains the test data files from the internal memory
of your RST Rheometer. Double click “DATA2” and the data files that have been stored in the RST
Rheometer memory will be listed in reverse chronology – from the most recently completed test to the first
test. The format for each file will look like one of the following:
o Run Single_63 04/28/14 10:28:25 am
o PROG1_32 04/10/14 15:30:05 pm
Select the test that you are interested in by double clicking on the data file and reviewing the measuring
points for that test.
To transfer files from the “DATA2” folder to the USB memory stick, press on the files one time and then on
the data transfter icon in the menu bar at the bottom of the screen. The files are automatically transferred
to the memory stick.
Choices for file format when exporting data include .csv, .bin, and .txt. Numerical data can be delineated
by either a decimal point or comma. Separator designation can either be a tab or a semicolon.
III.8.7 Service
This menu item is relevant only for service work and may be requested by our service technician.
III.8.8 USB Port and RS232 Port
USB Port provides information on use of the port. Host identifides USB memory stick when connected.
Device identifies the printer when connected.
RS232 povides sleelctions for band, Data Bits, Stop Bit and Parity.
III.8.9 Language
Select your preferred language for the RST Rheometer from this menu:
Figure III-52
Push the down arrow to see additional languages. Activate the language of choice by pressing the
preferred language icon.
