Brookfield Engineering Labs., Inc. page 20 Manual No. M14-223
• The hoses of the cooling circuit are connected to the cooling device KE using the quick-
fitting couplings.
• For that purpose you push the coupling sleeve slightly back, insert the hose connector
and let the coupling go. It will fasten the hose (without screwing or turning) by locking in.
• Pull lightly to check if the hoses fit tightly.
II.5 Setup for RST-CPS
II.5.1 Removing Safeguard RST-CPS
To remove the safeguard:
• Pullout the shipping pin. See Figure II-6, page 20.
• Turn up the lever
• Remove the black foam rubber (shipping protection). See Figure II-7, page 20.
Figure II-6
Figure II-7
