SYMBOLS USED THROUGHOUT THE INSTRUCTION MANUAL
Ensure
Free
Movement
Ensure Free
Movement
Apply
Grease
Apply Lubricant
Oil
Tighten
Tighten
Contact
Adhesive
Contact Adhesive
Screw
e C ment
BAG
1:1
Parts Bag Used
Degrease With
Motor Spray Do Not
Over Tighten
True-To-Scale Apply Oil
Apply Screw
Cement
Do Not
Over Tighten
Time
Time Pay attention here
PARTS REFERENCE
41361
8x14 Ball Bearing 41362
13x20 Ball Bearing 41363
X3S Screw Bag
4pcs. 4pcs.
41401
CNC 7075-3mm Lightweight Chassis
1pc.
41402
CNC 7075-5mm Front Shock Tower
1pc.
41403
CNC 7075-5mm Rear Shock Tower
1pc.
41404
Diff. Cap Joint (Lightweight)
2pcs.
41405
CNC 7075 Chassis Brace (Front/Rear)
1pc. 1pc.
1pc. 4pcs. 5pcs.
3x12 3x10 3mm
41503
CNC 7075 Chassis Brace (Front) 41504
CNC 7075 Chassis Brace (Rear)
1pc. 2pcs. 3pcs.
3x12 3x10 3mm
1pc. 2pcs. 2pcs.
3x10 3mm
1pc.
41406
CNC 7075 Suspension Holder,FF
1pc.
41407
CNC 7075 Suspension Holder,FR 41408
CNC 7075 Suspension Holder,RF 41409
CNC 7075 Suspension Holder,RR
1pc. 1pc. 1pc.
41410
Center CVD Cap Joint
1pc.
41507
Center CVD Shaft, Rear, 113mm
41411
Center CVD Shaft Set, Front, 101.5mm
1pc. 1pc. 1pc.
1pc.
1pc. 1pc. 1pc.
1pc.
41506
Center CVD Shaft, Front ,101.5mm 41412
Center CVD Shaft Set, Rear,113mm
1pc.
3x5
3x8
3x10
3x12
3x15
3x18
3x20
3x22
10pcs.
2pcs.
8pcs.
8pcs.
12pcs.
10pcs.
2pcs.
2pcs.
3x25
3x35
4x15
4x18
3x8
3x10
3x15
3x16
3x35
4x12
4x16
2pcs.
2pcs.
1pc.
4pcs.
10pcs.
7pcs.
6pcs.
2pcs.
4pcs.
8pcs.
4pcs.
41413
Alum. Chassis Brace Mount
1pc. 1pc. 1pc.
4x20
OPT 41414
Alum. Rear Hub Carrier L.R
4mm
OPT
1pc. 1pc.
2pcs. 4pcs. 2pcs.
8x16x5 13x20x4
1pc.
