OFNA Racing X3 Sabre - Manual (Page 38)

61
71 ASSEMBLY OF THE SHOCK ADJUST RING
ASSEMBLY OF THE SHOCK BALL END 72
Assemble both left and right sides.
REAR SHOCK FRONT SHOCK
Oil
41007
19x1.5 O-RING
Step 2 Step 1
Fit the o-ring into groove before
assembly.
Step detail
TOP
41007
41515 Oil
Oil
Step detail
Use tools to tighten as picture shown.
REAR SHOCK FRONT SHOCK .....x4
30403
6mm Ball
30403
30403
41350
41350
10mm
Step detail
4
0
m
m
2
9
m
m
Do Not
Over Tighten
Do Not
Over Tighten
Attention distance.
73 SETTING THE SHOCK REBOUND TO 100% (HIGH REBOUND)
HOC
OI
S
K
L
Step detail
Step 1
Step 2
Step 5
Step 3
Step 4
41013
41329
FRONT (SHORT ) SHOCKS OIL #55 REAR (LONG ) SHOCKS OIL #40
3~5x
UP & DOWN
Step 6
TIGHTENED HALF WAY 50% TIGHTENED 100%
•Leave the filled shock vertically for several
minutes with the shock shaft fully extended.
•The remaining air bubbles will release.
Time
NO.9
BAG
NO.9
BAG
NO.9
BAG
.....x4
x2
x2
x2
x2
Assemble both left and right sides.
