Page 27: No.10

Text mode
Original mode

.....x2

94041
3mm
Nylon Nut

94003
3X10MM
Flat Head Hex Screw

.....x2

ASSEMBLY OF THE CENTER DIFF. ONTO CHASSIS

NO.5

BAG

ASSEMBLY OF THE FUEL TANK

94027
4X16mm
Flat Head Hex Screw

.....x2

NO.4

BAG

ASSEMBLY OF THE REAR GEAR CASE ONTO CHASSIS

GEAR

GREASE

Apply a small amount of grease.

Step detail

94026
4X12mm
Flat Head Hex Screw

.....x4

Step 1

Step 2

Step 3

94003
3x10mm
Hex Screw

.....x1

94002
3x8mm
Hex Screw

.....x2

94001
3x5mm
Hex Screw

.....x1

94026
4X12mm
Flat Head Hex Screw

.....x2

94026

41352

41508

94001

41051

94003

94002

41342

41051

NO.1

BAG

NO.10

94041

94003

94026

94027

40620BK

Screw
