Page 18: Assembly of the steering tie-rod

ASSEMBLY OF THE FRONT PLATE ONTO SERVO SAVER

NO.3

BAG

NO.3

BAG

Step 1

Step 2

41349

94004

41351

94061

40074

94003

94061

40074

41316

94041

41503

Ensure

Free

Movement

Ensure

Free

Movement

rew

.....x1

94041
3mm
Nylon Nut

94003
3x10mm
Hex Screw

.....x4

40074
6x10x3
Ball Bearing

.....x2

94061
3x6x0.5mm
Washer

.....x3

94004
3x12mm
Hex Screw

ASSEMBLY OF THE STEERING TIE-ROD

41331
7x8.5mm Ball

.....x4

Make two steering rods for left and right hand sides.

Step detail

Approx. 26mm

Step detail

36790
4x46mm
Turnbuckle

.....x2

41331

41350

36790

41350

41331

Use tools to tighten as shown.

NO.3

BAG

RIGHT SIDE

Note the locking direction!

Step detail

LEFT SIDE

94063
3x16mm
Flat Head Hex Screw

.....x2

Face the counter-clockwise mark to the gear case and
make opposite direction for easy adjustment.

RIGHT SIDE

Step detail

94063

ASSEMBLY OF THE STEERING TIE-ROD

94004

Counter-Clockwise

Clockwise

Tighten
