ASSEMBLY OF THE REAR PINION GEAR AND CVD SHAFT

NO.4

BAG

25

26

NO.4

BAG

41302

4x6mm

41344

94075

S rew c

Cem

ent

94068
4x6mm
Set Screw

.....x1

94075
5x8x0.3mm
Washer

.....x1

40024

40024

40024
13x16x0.2mm
Shim

.....x2

Adjust the backlash with the Shims.

ASSEMBLY OF THE REAR DIFFERENTIAL ONTO GEAR CASE

ASSEMBLY OF THE REAR GEAR CASE COVER
AND LOWER ARM HOLDERS

94021
3x15mm
Flat Head Hex Screw

.....x2

3x35mm
Hex Screw

.....x2

94021

94065

41409

Tighten

41344

Tighten

NO.4

BAG

NO.1

94065
