Page 28: No.11

94005
3x15mm
Hex Screw

ASSEMBLY OF THE STEERING ROD

NO.2

BAG

ASSEMBLY OF THE STEERING SERVO AND RADIO TRAY

NO.11

BAG

94005
3x15mm
Hex Screw

.....x1

94004
3x12mm
Hex Screw

.....x2

Step detail

Note the locking direction!

Step 1

Step 2

Step detail

Use tools to tighten as shown.

Approx. 19mm

30411
6mm Ball and scoket

.....x2

.....x1

94041
3mm
Nylon Nut

.....x1

Use the screw provided with
your servo .

94040
3x8X0.5mm
Washer

.....x4

Sanwa/Airtronics

Futaba

HiTech

Choose the right servo horn adapter for your servo.

NO.10

BAG

ASSEMBLY OF THE FUEL TANK ONTO CHASSIS

94019
3X10mm
Flat Head Hex Screw

.....x2

41508

Step 1

37410

41508

94019

30411

94005

94041

94005

94004

38280

41359

41350

NO.11

10769

94040

41359

41358

To receiver Ch1

Step 2

Servo
not included

Counter-Clockwise

Clockwise

Note orientation of servo arm when
servo is at neutral.

94040
