Page 25: No.5

background image

39

ASSEMBLY OF THE REAR CENTER BRACE

NO.4

BAG

40

ASSEMBLY OF THE FRONT CENTER DIFF MOUNT

NO.5

BAG

41

41504

94011

94011
4x15mm
Hex Screw

.....x1

41325

39242

41356

38274

41356

94044

94033

41327

41323

41326

41323

Step 1

Step 2

Step 3

Step detail

Approx. 3.5mm

94044
2.5x8mm
Hex Screw

.....x2

39242
5x8x2.5mm
Ball Bearing

.....x1

94033
3x3mm
Set Screw

.....x1

ASSEMBLY OF THE REAR CENTER DIFF MOUNT

41327

41323

41356

41356

41356

39242

41325

38274

94044

Step detail

Approx. 4mm

NO.5

BAG

FRONT SIDE

REAR SIDE

94044
2.5x8mm
Hex Screw

.....x2

39242
5x8x2.5mm
Ball Bearing

.....x1

94033
3x3mm
Set Screw

.....x1

94017
3x8mm
Flat Head Hex Screw

.....x1

Step 1

Step 2

Step 3

94044

94017

41326

41323

41326

41323

41326

94044

94033
