Page 14: 8assembly of the front shock stay, No.9

background image

6

5

ASSEMBLY OF THE FRONT DIFFERENTIAL INTO
GEAR CASE

94021

94043

41406

ASSEMBLY OF THE FRONT GEAR CASE COVER

40024

40024

NO.1

BAG

Tighten

41344

NO.2

BAG

7

40024
13x16x0.2mm
Shim

.....x2

94021
3x15mm
Flat Head Hex Screw

.....x2

94043
3x35mm
Hex Screw

.....x2

Adjust the backlash with the Shims.

Tighten

8

ASSEMBLY OF THE FRONT SHOCK STAY

Tighten

40865

41330

41402

40865
4mm
Nylon Nut

.....x2

NO.9

BAG

S

re

w

c

C

em

t

en

S

c

re

w

C

e

m

e

n

t
