Kit components – Waterworks Transit Deck Mounted Low Profile Concealed Tub Filler with Metal Handshower and Metal Lever Handles User Manual
Page 12
11
10
W W W.WAT ERWOR KS.COM/ST UDIO
PRODUC T SUPPORT: 1 (800) 927-2120 (EX T 2)
*FINISH/COLOR MUST BE SPECIFIED WHEN ORDERING
++SUPPLIED A S A PAIR
ST YLES: TRTF01, TRTF10
KIT COMPONENTS
T EE
O-R ING
WA SHER
DI V ERT ER SH U T T L E
O-R ING
CL IP
SPR ING
WA SHER
O-R ING
DI V ERT ER ROD
O-R ING
WA SHER
N U T
RU BBER WA SHER
CHECK VA LV E
HOUSING
390669
TEE KIT
KIT COMPONENTS
451919
DIVERTER KIT
