Kit components – Waterworks Transit Deck Mounted Low Profile Concealed Tub Filler with Metal Handshower and Metal Lever Handles User Manual
Page 10
7
6
W W W.WAT ERWOR KS.COM/ST UDIO
PRODUC T SUPPORT: 1 (800) 927-2120 (EX T 2)
*FINISH/COLOR MUST BE SPECIFIED WHEN ORDERING
++SUPPLIED A S A PAIR
ST YLES: TRTF01, TRTF10
KIT COMPONENTS
258790
CLOCKWISE ON
VALVE CARTRIDGE
H A N DSHOW ER
O-R ING
RU BBER WA SHER
M E TA L WA SHER
N U T
VA LV E BODY
F LOW R EGU L AT ING
CHECK VA LV E
WA SHER
O-R ING
COL L A R
O-R ING
FACE PL AT E
SCR E W
033792*
SPR AY KIT
KIT COMPONENTS
203324
CLOCKWISE ON SIDE
BODY KIT
