Opus ® Concealed Deck Mounted Tub Filler With Cross Handles
4/05
W A T E R W O R K S ®
These guidelines have been prepared for the professional contractor to aid in the installation of:
OPUS CONCEALED DECK MOUNTED TUB FILLER WITH CROSS
HANDLES (OPTU91-K)
All dimensions are based on original specifications and are subject to change and variation.
Please consult your Design Associate for current specifications.
Installation Guidelines
2
➢ Remove the locking nut, gaskets, and plastic spacer from the
handshower escutcheon assembly and insert through the
mounting hole.Then re-attach and tighten the locking nut,
gaskets, and plastic spacer if needed (used for deck surfaces
less than 1½" thick) until fully secure (see fig.3).
➢ Feed the male threaded end of the hose up through the
escutcheon assembly and attach the handshower using the
gasket provided (see fig.3).
➢ Connect the female tapered end of the hose to the bottom
of the tee assembly at the base of the spout.
➢ Connect the hot and cold water supplies to the side valve
bodies.
➢ After installation, unscrew and remove the aerator assembly
from the spout. Carefully open the hot and cold valves fully
to flush out any debris in the supply lines. Once the lines
have been flushed , close the valves and reinstall the aerator
assembly. DO NOT divert the flow of water to the
handshower until this step is completed.
➢ IMPORTANT: It is necessary to check for leaks and proper
function of mixer prior to being enclosed.
➢ If further assistance is required, please contact Product
Support at:
1-800-927-2120 (8AM-7PM EST).
