8. Allow the valve to run in warm position for a few
minutes to completely flush the system. If system is
quite dirty, remove the cartridge to ensure proper
flushing.
9. IMPORTANT: This valve is equipped with a limit stop
screw (8, 9) to be used to limit the valve handle from
being turned to excessively hot water discharge
temperatures.
10. Setting the limit stop screw : Open the valve to the
maximum desired temperature then turn the limit
stop screw (8) in until it seats.
11. WARNING: FAILURE TO ADJUST THE LIMIT
STOP SCREW PROPERLY MAY RESULT IN
SERIOUS SCALDING.
INSTALL THE TRIM:
Note: Part numbers refer to trim and/or rough exploded
view drawings.
12. Hand tighten the dome cover (5) completely onto
the packing nut (10). The dome cover MUST be
tightened to prevent damage to the handle.
13. Moisten the o-ring (8a) then slide the diverter
assembly and plate (6-6b, 8-8b) trim over the dome
cover while making sure the diverter shaft/handle (6)
is aligned with the diverter spindle (27-30).
IMPORTANT: The diverter must be properly aligned
and the handle must rest at 6 o-clock position. If the
handle and diverter spindle are not properly aligned,
the valve will not function. See Figure 1.
14. Secure the plate to the wall using the two screws
(7).
15. Pull off the indice assembly (2-2c) from the handle,
position then hold handle spacer (4) onto the spindle.
Secure the handle by tightening the screw (3) then
reinstall the indice assembly.
Installation Guidelines
W A T E R W O R K S
Waterworks is a registered trademark of Waterworks Inc.
SERVICE
NOTE: REFER TO EXPLODED VIEW DRAWING
FOR SERVICE PART CALL OUTS. A TROUBLE
SHOOTING GUIDE IS ALSO INCLUDED.)
17. Remove valve trim.
18.Shut-off water to the valve. Remove the service
stop cap (26), stop retainer (25) and tighten valve
stop (22) with a
3
16
" hex wrench.
19.CAUTION: Before removing main cap/bonnet nut
(3) use the following sequence to avoid damage to
the stem:
-Unthread the adjustment screw (9) until the o-ring
is fully exposed.
-Open valve to full hot and unscrew cap/bonnet nut
(3).
Loosen but leave packing nut (10) in place when
removing cap/bonnet nut to avoid damage to
packing assembly.
-Control stem/spindle (11-14) will be removed with
the cap/bonnet nut.
20.Replace appropriate parts as needed and inspect
seats and o-rings for any visible wear.
21.Extended Service:
-Control Stem/Cartridge: the end of the control
stem that is the furthest point into the valve is the
most important part. This houses the stainless steel
control piston (12).
-Shake the stem and listen for the piston to be
moving back and forth. A freely moving piston
makes a knocking noise similar to an empty spray
paint can.
-If a noise is not detected, check for obstructions
such as flux, solder, saw dust etc. Soak in mineral
deposit de-scaler if necessary.
-Replace the cartridge if the piston does not move
freely.
-Seat replacement: requires seat replacement tool
and appropriate parts.
22.Reinstall the valve in reverse sequence.
If further assistance is required, please contact Product
Support at 1-800-927-2120 (8am-7pm EST).
Julia Pressure Balance Valve Trim with Diverter
16. Open the valve and confirm the temperature
setting, adjust as required. Verify that the diverter is
functioning properly. NOTE: a small amount of
water may trickle from the tub spout when the
diverter is set in the shower position and is not
considered a defect.
10.06.06
These guidelines have been prepared for the professional contractor to aid in the installation of:
JULIA PRESSURE BALANCE VALVE TRIM WITH DIVERTER (JUSV41-K, 42-K, 43-K &
GUSV87R) All dimensions are based on original specification and are subject to change and variation.
Please consult your Design Associate for current specifications.
